HD-503SK CNC Busbar Processing Machine

²  The shearing unit uses sharp shearing, the incision interface is flat, no droop and burrs and waste, beautiful shape.

²  The punching unit uses an united six-mode template in tooth shape to make sure the upper mold and the lower mold are absolutely in the center, improve the mold concentricity and longten the working life.

²  The turnplate is in tooth shape with good view and high strength. No need to frequently change molds, labor intensity is highly reduced. It is easy and quick to use.

²  Producing efficiency is obviously higher than a traditional one.

²  The bending unit uses an single-decker working tab le,   which   can   make   sure    that    three  working positions can do their operations at same time without bothering the others.

²  By changing different mold it can do flat bending, a nd      vertical       bending.       CNC       controls  the bending angle by an imported PLC control syste m.Input    a    busbar    thickness     and     an   angle on a CNC touching screen, or input a height and    a    side    length    to    get    the    result  what you need, such as Z bending. Bending precisi on is ±1, repeat precision ±1, repeat precision ± 0.3.

²  The user can input processing data in advance, ant he      system will  do the process according to the inputted data. The field da ta can be put into the system at anytime and be pag ed out for using repeatedly.

²  The machine has four casters so it is easily to be moved everywhere there are two operating modes, manual button and foot switch, which is easily for worker to operate and use.

²  Based on user's requirement, it can do all kinds of special shape processing with different molds or equipping parts
