OMT Series Air Driven Gas Booster Pump

This series of pump has double stage. It can amplify extremely low pressure into very high pressure. The drive gas pressure≤8bar. The rage of inlet gas pressure is 0.5-10bar. The maximum pressure can be up to 80Mpa. The pump is made of aluminum alloy and stainless steel.

The diameter of its drive piston is 160mm. Both pump heads can cool the exhaust gas.
Availability:

This series of pump has double stage. It can amplify extremely low pressure into very high pressure. The drive gas pressure≤8bar. The rage of inlet gas pressure is 0.5-10bar. The maximum pressure can be up to 80Mpa. The pump is made of aluminum alloy and stainless steel.

The diameter of its drive piston is 160mm. Both pump heads can cool the exhaust gas.

OMT-series

Type Pressure ratio Min. Gas
Inlet Pressure
PA (bar)
Max. Gas
Inlet Pressure
PA (bar)
Max. Allowed
Outlet Pressure
PB (bar)
Outlet Pressure
Calculate
Formula PB
Gas Inlet Gas Outlet Max. Flow Ln/min
@PL=6bar
OMT25 25:1 0.1 bar 10 bar 200bar 25PL+3.5PA ZG1/4 ZG1/4 136@PA=8
OMT40 40:1 0.1bar 10bar 320bar 40PL+6PA ZG1/4 ZG1/4 124@PA=8
OMT10/60 10:1/60:1 0.1bar 10bar 480bar 60PL+6PA ZG1/4 ZG1/4 84@PA=8
OMT25/60 25:1/60:1 0.1bar 25bar 480bar 60PL+2.5PA ZG1/4 ZG1/4 80@PA=15
OMT100 100:1 0.1bar 10bar 800bar 100PL+10PA ZG1/4 ZG1/4 63@PA=8

PL=drive pressure PA=input gas pressure PB=output gas pressure


OMT-Series-Air-Driven-Gas-Booster-Pump_01

OMT-Series-Air-Driven-Gas-Booster-Pump_02

OMT-Series-Air-Driven-Gas-Booster-Pump_03
